FL Series:
Shape Your Own Screen
Our flexible and bespoke LED wall solution transforms your creative vision into reality, guiding you seamlessly from the first sketch to the final installation.
FL SERIES DESCRIPTION
The FL Series Flexible LED screen transforms any vision into reality, offering limitless options for shape and size. Imagine columns, tunnels, trees, trumpets, ribbons, spirals, spheres, or even CAN-shaped displays—the creative possibilities are truly boundless.
Its bendable structure, crafted with soft yet durable PCBs, lets you shape convex and concave curves that snap easily onto metal frames with built-in magnets. This flexibility makes it the go-to choice for ambitious and unconventional displays. From TV studios and museums to tradeshows, bars, malls, casinos, hotels, and theme parks, these screens create captivating, dynamic visuals that immerse and amaze.
From the first sketch to the final installation, we turn your boldest ideas into dazzling reality.
Unleash your creativity with the FL series—the ultimate solution for building seamless, one-of-a-kind LED displays that adapt effortlessly to any structure or environment.
KEY FEATURES
Highly Flexible with Concave & Convex Curves
 |
High Resolution Modules
 | With its versatile pitch options, you can enjoy stunning high-resolution video and transform any space into a canvas for imaginative architectural displays. |
Custom Frames
our FL led tiles can be attached to virtually any surface via magnets, the specific framing structure is designed and manufactured to accomplish your unique design and shape |  |
Advanced Magnetic Connection System
 | Magnetic mounts, along with set screw ports, allow for attachment to virtually any metal surface or LED video design. |
Easy Front Maintenance
Single module replacement made easy, improving serviceability in the field. |  |
Creative Configurations
 | Creating angles, curves, cylindrical and seamless designs will be easy with FL Series Flexible led displays |
Accessories
 |
FL SERIES SPECIFICATIONS
3840HZ | 1000NITS | 281 Trillion | 140°/140° | 5000:1 |
REFRESH RATE | BRIGHTNESS | COLOR CAPABILITY | VIEWING ANGLE | CONTRAST RATIO |
FL SERIES 0.9MM SMD INDOOR-FL091
PIXEL PITCH: 0.9375mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 256x128dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 800nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.12Kgs (0.26 lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
FL SERIES 1.2MM SMD INDOOR-FL121
PIXEL PITCH: 1.25mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 256x128dots | 192x96dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 800nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
FL SERIES 1.56MM SMD INDOOR-FL151
PIXEL PITCH: 1.56mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 204x102dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 800nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
FL SERIES 1.8MM SMD INDOOR-FL181
PIXEL PITCH: 1.8mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 172x86dots | 128x64dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 1000nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Rear AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE:- 20℃~+40℃ |
FL SERIES 2MM SMD INDOOR-FL201
PIXEL PITCH: 2.0mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 160x80dots | 120x60dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 1000nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
FL SERIES 2.5MM SMD INDOOR-FL251
PIXEL PITCH: 2.5mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 128x64dots | 96x48dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 1000nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE:- 20℃~+40℃ |
FL SERIES 3MM SMD INDOOR-FL301
PIXEL PITCH: 3.0mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 104x52dots | 80x40dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 1000nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT:0.3Kgs (0.66 lbs) | 0.17Kgs (0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
FL SERIES 4.0MM SMD INDOOR-FL401
PIXEL PITCH: 4.0mmPIXEL CONFIGURATION & PACKAGE: 3 in 1 SMDMODULE PIXEL RESOLUTION (H x W): 60x30dotsCABINET PIXEL RESOLUTION (H x W): CustomizedBRIGHTNESS: 1000nitsREFRESH RATE: 3840Hz | CABINET SIZE: CustomizedMODULE WEIGHT: 0.17Kgs ( 0.37lbs)ACCESSIBILITY: Front AccessIP RATING: IP30CONTRAST RATIO: 5000:1WORKING TEMPERATURE: -20℃~+40℃ |
