LDF Series

Interactive, Immersive


LDF Series transforms any space into an interactive LED dance floor, inviting everyone to dive into a world of vibrant lights, excitement, and unforgettable moments.



LDF SERIES DESCRIPTION


LDF SERIES transforms any space with its interactive LED dance floor tiles, equipped with sensors that burst into vibrant colors and lifelike visuals. As people move and dance, the floor responds instantly, creating a captivating and playful experience.

These dance floors elevate any event, making them a popular choice in shopping malls, conferences, auto shows, and more, where they bring the magic of interactive technology to life.


The pixel pitch is available for p2.,5 p2.6, p2.9, and p3.9.




KEY FEATURES


Complete Set Available

Step into a world of effortless procurement with our all-in-one LED dance floor sets, crafted to boost your workflow and spark unforgettable moments of fun.


Real-time Interactive with Multi-point touch


Featuring a built-in interactive system with limitless interaction points, this ultra-sensitive LED responds in just 0.02 seconds, creating a dazzling visual spectacle that captivates audiences and leaves a lasting impression, dramatically boosting engagement.

Super load-bearing performance

Designed with full-back reinforcement to evenly spread force across the surface and paired with galvanized floor support, it boasts a loading capacity exceeding 3T per square meter. This strength easily supports energetic crowds, making it a standout choice for stage shows, museums, and bustling venues.


Anti-slip


A+ grade imported polymer PC mask, crafted with a unique anti-slip design that ensures a secure grip in any environment.

Wear-resistant and flame-retardant

Crafted from top-tier imported PC polymer, this mask boasts exceptional wear resistance, impressive flexibility, and stands up to heat, cold, and fire.


High Protection


The panel is expertly sealed with a sturdy mask and shell, reinforced by waterproof rubber rings and three-proof glue in every screw hole. This meticulous protection ensures it withstands moisture and water, earning its IP54 rating for dust and water resistance.

Excellent heat dissipation & super sound-off

Expertly crafted for exceptional heat management, this device runs in near silence and cools in a flash, so your tiles always deliver steady, dependable performance.


Quick Installation


Thanks to its independent cabinet foot design, you can position it horizontally in no time and assemble it with impressive speed.

Front Maintenance

Enjoy hassle-free maintenance and quick replacements from the front, all without needing a technician or special tools. Designed to be simple and user-friendly for everyone.


Flexible Interactive Contents


Enjoy 30 sets of interactive content for free, with 120 more available to choose from. We also offer custom content tailored to your needs, and can even use your own materials.


LDF SERIES SPECIFICATIONS




3840HZ

1000NITS

281 Trillion

160°/160°

5000:1


REFRESH RATE

BRIGHTNESS

COLOR CAPABILITY


VIEWING ANGLE


CONTRAST RATIO





LDF SERIES 2.5mm SMD Indoor

PIXEL PITCH: 2.5mm

PIXEL CONFIGURATION & PACKAGE: 3 in 1 SMD

MODULE PIXEL RESOLUTION (H x W): 100x100dots

CABINET PIXEL RESOLUTION (H x W): 200x400 dots

BRIGHTNESS: 1500 nits

REFRESH RATE: 3840Hz

CABINET SIZE: 500x500mm (19.69x19.69inch) | 500x1000mm (19.69x39.38inch)

CABINET WEIGHT: 11Kgs (16.53 lbs) 22

ACCESSIBILITY: Front Access

IP RATING: IP30

CONTRAST RATIO: 5000:1

WORKING TEMPERATURE: -20℃~+40℃

LDF SERIES 2.6mm SMD Indoor

PIXEL PITCH: 2.97mm

PIXEL CONFIGURATION & PACKAGE: 3 in 1 SMD

MODULE PIXEL RESOLUTION (H x W): 84x84dots

CABINET PIXEL RESOLUTION (H x W): 168x168dots

BRIGHTNESS: 1000 nits

REFRESH RATE: 3840Hz

CABINET SIZE: 500x500mm (19.69x19.69inch)

CABINET WEIGHT: 7.5Kgs (16.53 lbs)

ACCESSIBILITY: Front Access

IP RATING: IP30

CONTRAST RATIO: 5000:1

WORKING TEMPERATURE: -20℃~+40℃

LDF SERIES 2.9mm SMD Indoor

PIXEL PITCH: 3.91mm

PIXEL CONFIGURATION & PACKAGE: 3 in 1 SMD

MODULE PIXEL RESOLUTION (H x W): 64x64dots

CABINET PIXEL RESOLUTION (H x W): 128x128dots

BRIGHTNESS: 1000 nits

REFRESH RATE: 3840Hz

CABINET SIZE: 500x500mm (19.69x19.69inch)

CABINET WEIGHT: 7.5Kgs (16.53 lbs)

ACCESSIBILITY: Front Access

IP RATING: IP30

CONTRAST RATIO: 5000:1

WORKING TEMPERATURE: -20℃~+40℃

LDF SERIES 3.9mm SMD Indoor

PIXEL PITCH: 2.604mm

PIXEL CONFIGURATION & PACKAGE: 3 in 1 SMD

MODULE PIXEL RESOLUTION (H x W): 96x96dots

CABINET PIXEL RESOLUTION (H x W): 192x192dots

BRIGHTNESS: 4000 nits

REFRESH RATE: 3840Hz

CABINET SIZE: 500x500mm (19.69x19.69inch)

CABINET WEIGHT: 7.5Kgs (16.53 lbs)

ACCESSIBILITY: Rear Access

IP RATING: IP65

CONTRAST RATIO: 5000:1

WORKING TEMPERATURE: -20℃~+40℃
