SPRO COB Series
Unparalleled Durability and Clarity
brings ultimate in durability ,with superior impact, dust,moisture protection, designed for spaces where reliability & engagement are key.
SPRO COB SERIES DESCRIPTION
SPRO-COB Series micro led video wall brings you the ultimate in durability and interactive capabilities. With superior impact, dust, and moisture protection, these displays are designed for spaces where reliability and user engagement are key.
The COB (Chip on Board) technology enhances the resilience of LED panels, making them the ideal choice for high-traffic such as retail space, corporate environments, interactive exhibits, education and training, shopping mail.
SPRO COB Series features 10000:1 contrast ratio, up to 600nits and 170° viewing angle, delivering vivid image even in bright condition and the recommended pixel pitch is P0.7, P0.9 ,P1.25, P1.56 ,P1.875, catering to fine pitch needs for ultra-high-definition visuals
KEY FEATURES
Full Flip-chip COB Design
Module, receiving cards and power supplies can be maintained front, no maintenance channels needed ；Greatly improving the installation efficiency, also it will reduce the occurrence of some problems caused by cable. |  |
16:9 Golden Ratio
 | Standard 27.5" Size FHD/4K Pixel to Pixel Resolutions |
High Protection Package Technology
can be cleaned directly with wet cloth, completely solve the damage caused by bumps, impacts, moisture, salt spray corrosion, electrostatic breakdown etc. |  |
0.3mm Super thin glue, unique encapsulation tech
 | 0.3mm ultra-thin colloid Liquid glue + filling process long-term use, Non-deformation module, high consistency and high protection |
Three-in-one Integrated HUB With Front & Rear Access
 |
Totally Cable-less Connection
 | Modular design and work stable |
Single Module Power Consumption 75W
P0.9 for common negative energy-saving design, P1.2 and above for common positive voltage divider design |  |
Multiple installation
 | Support aluminum base stacking, wall mounted |
Accessories
 |
SPRO COB SERIES SPECIFICATIONS
3840HZ | 1000NITS | 281 Trillion | 170° / 170° | 20000:1 |
REFRESH RATE | BRIGHTNESS | COLOR CAPABILITY | VIEWING ANGLE | CONTRAST RATIO |
SPRO COB SERIES 0.7MM INDOOR-S071PRO COB
PIXEL PITCH:0.7mmPIXEL CONFIGURATION & PACKAGE:COBMODULE PIXEL RESOLUTION ( H X W):240x135dotsCABINET PIXEL RESOLUTION ( H X W):480x270dotsBRIGHTNESS: 400nitsREFRESH RATE:3840Hz | CABINET SIZE:600x337.5mm (23.62x13.28 inch)CABINET WEIGHT:3.4Kgs ( 7.71 lbs)ACCESSIBILITY:Front AccessIP RATING:IP30CONTRAST RATIO:20000:1WORKING TEMPERATURE:-20℃~+40℃ |
SPRO COB SERIES 0.9MM INDOOR-S091PRO COB
PIXEL PITCH:0.9375mmPIXEL CONFIGURATION & PACKAGE:COBMODULE PIXEL RESOLUTION ( H X W):160x180dotsCABINET PIXEL RESOLUTION ( H X W):640x360dotsBRIGHTNESS:400-450nitsREFRESH RATE:3840Hz | CABINET SIZE:600x337.5mm (23.62x13.28 inch)CABINET WEIGHT:3.4Kgs ( 7.71 lbs)ACCESSIBILITY:Front AccessIP RATING:IP30CONTRAST RATIO:20000:1WORKING TEMPERATURE:-20℃~+40℃ |
SPRO COB SERIES 1.25MM INDOOR-S121PRO COB
PIXEL PITCH:1.25mmPIXEL CONFIGURATION & PACKAGE:COBMODULE PIXEL RESOLUTION ( H X W):240x135dotsCABINET PIXEL RESOLUTION ( H X W):480x270dotsBRIGHTNESS:450-450nitsREFRESH RATE:3840Hz | CABINET SIZE:600x337.5mm (23.62x13.28 inch)CABINET WEIGHT:3.4Kgs ( 7.71 lbs)ACCESSIBILITY:Front AccessIP RATING:IP30CONTRAST RATIO:20000:1WORKING TEMPERATURE:-20℃~+40℃ |
SSPRO COB SERIES 1.56MM INDOOR-S151PRO COB
PIXEL PITCH:1.5625mmPIXEL CONFIGURATION & PACKAGE:COBMODULE PIXEL RESOLUTION ( H X W):192x108dotsCABINET PIXEL RESOLUTION ( H X W):384x216dotsBRIGHTNESS:400-450nitsREFRESH RATE:3840Hz | CABINET SIZE:600x337.5mm (23.62x13.28 inch)CABINET WEIGHT:3.4Kgs ( 7.71 lbs)ACCESSIBILITY:Front AccessIP RATING:IP30CONTRAST RATIO:20000:1WORKING TEMPERATURE:-20℃~+40℃ |
SPRO COB SERIES 1.87MM INDOOR-S181PRO COB
PIXEL PITCH:1.875mmPIXEL CONFIGURATION & PACKAGE:COBMODULE PIXEL RESOLUTION ( H X W):160x90dotsCABINET PIXEL RESOLUTION ( H X W):320x180dotsBRIGHTNESS:450-450nitsREFRESH RATE:3840Hz | CABINET SIZE:600x337.5mm (23.62x13.28 inch)CABINET WEIGHT:3.4Kgs ( 7.71 lbs)ACCESSIBILITY:Front AccessIP RATING:IP30CONTRAST RATIO:20000:1WORKING TEMPERATURE:-20℃~+40℃ |
